MPS MP1484EN 3A Synchronous Step Down Converter IC (2)
Discover the MPS MP1484EN 3A 340KHz synchronous step down converter IC, available as a two-piece set. These new chips are ideal for power regulation tasks. Product Code: MP1484EN
High-Efficiency Power Conversion
The MPS MP1484EN is a high-frequency, synchronous, rectified, step-down switch-mode converter with built-in internal power MOSFETs. This integrated circuit offers a very compact solution capable of delivering 3A continuous output current over a wide input supply range with excellent load and line regulation. The MP1484EN is designed for applications requiring efficient power management and voltage step-down capabilities. Its synchronous operation results in higher efficiency compared to non-synchronous converters, especially at higher output currents, making it a smart choice for power-conscious designs where thermal performance is critical.
Advanced Features and Reliable Performance
This step-down converter operates at a fixed switching frequency of 340KHz, which allows for the use of small, low-cost inductors and capacitors, contributing to a smaller overall solution size. Key specifications include its ability to handle a 3A output current and its synchronous rectification. The device comes in a SOIC8N package, a common and convenient package type for surface-mount applications. Markings on the chip include MPS, MP1484EN, MP1484, 1484EN, and MP 1484 EN, ensuring easy identification for assembly and replacement tasks in various electronic projects.
Versatile Applications for Modern Electronics
The MP1484EN synchronous step-down converter IC is suitable for a wide array of applications. It's commonly found in distributed power systems, networking systems, FPGA, DSP, ASIC power supplies, and green electronics or appliances. Its capability to efficiently convert higher input voltages to lower output voltages makes it ideal for powering microcontrollers, sensors, and other low-voltage digital or analog components. Whether you're designing consumer electronics, industrial controls, or automotive systems, this converter provides a reliable power solution for demanding applications.
Optimized Efficiency with Synchronous Rectification
One of the primary benefits of the MP1484EN is its synchronous rectification. Unlike traditional buck converters that use a diode for rectification, synchronous converters replace this diode with an actively controlled MOSFET. This significantly reduces conduction losses, particularly at higher output currents, leading to improved overall efficiency. Higher efficiency means less power is wasted as heat, which can reduce the need for bulky heatsinks, save energy, and improve the reliability and lifespan of the end product by operating at lower temperatures.
Convenient Packaging for Your Projects
This offering includes two pieces of the brand new MP1484EN converter ICs. They are supplied in a reel package, which is ideal for automated assembly processes or for convenient storage if you are purchasing them for smaller projects or repairs. The reel packaging helps protect the delicate leads of the SOIC8N package during transit and handling, ensuring that the components arrive in pristine condition. Having two pieces allows for immediate use in a project or having a spare on hand for future needs or replacements.
Essential Handling and Soldering Guidelines
Due to its nature as an ESD sensitive device, it is crucial to follow proper Electrostatic Discharge (ESD) practices when handling the MP1484EN. This includes using grounded wrist straps and ESD-safe workstations. For soldering, especially for replacing this type of chip, specialized equipment such as a hot-air soldering station and a pre-heating station are necessary. It is also recommended to prebake the chip at 125 degrees Celsius for 24 hours to remove any absorbed moisture, preventing potential damage during the reflow soldering process.
Preventing Damage Through Prebaking
Prebaking moisture-sensitive devices like the MP1484EN is a critical step, particularly for components stored outside of moisture barrier bags or in humid environments. During the rapid temperature increase of reflow soldering, any trapped moisture within the IC package can turn into steam, expand, and cause internal delamination or micro-cracks, often referred to as the "popcorn effect." Following the prebaking recommendation of 125°C for 24 hours helps to ensure the component's integrity and reliability after soldering, leading to a successful and durable assembly.
Guaranteed Authenticity and Support
The MP1484EN chips offered are brand new, and the pictures provided are of the actual items you will receive, ensuring transparency and trust in your purchase. These genuine MPS components are crucial for achieving the specified performance and reliability in your power management circuits. Furthermore, the purchase comes with a 180-day warranty, providing peace of mind and assurance of quality. This warranty covers defects and offers support, making it a secure investment for your electronic design and repair needs, especially when integrated into critical power systems.
